75 degree Off Beam Box End Wrench (FM8A-O)
75 degree Off Beam Box End Wrench (FM8A-O)
Features:
- 75 degree Offset wrench heads for recessed and hard to reach fasteners.
- Features a fixed box wrench on one end with a twisted 90 swivel socket on opposite end.
- Vertical wrench body provides comfortable grip and additional leverage.
- Meets and exceeds ASME/ ANSI torque specifications.
Specification：
| Metric | ||||
| Size | A | B | L (mm) | W (g) |
| 8 | 17.5 | 7.5 | 165.0 | 102.0 |
| 9 | 17.5 | 7.5 | 165.0 | 102.0 |
| 10 | 17.5 | 7.5 | 165.0 | 140.0 |
| 11 | 17.5 | 7.5 | 165.0 | 140.0 |
| 12 | 19.5 | 8.5 | 185.0 | 178.0 |
| 13 | 19.5 | 8.5 | 185.0 | 178.0 |
| 14 | 23.5 | 9.5 | 200.0 | 184.0 |
| 15 | 23.5 | 9.5 | 200.0 | 184.0 |
| 16 | 27 | 10.5 | 220.0 | 268.0 |
| 17 | 27 | 10.5 | 220.0 | 268.0 |
| 18 | 29 | 12.0 | 260.0 | 336.0 |
| 19 | 29 | 12.0 | 260.0 | 336.0 |
| SAE | ||||
| Size | A | B | L (mm) | W (g) |
| 5/16" | 17.5 | 7.5 | 165.0 | 102.0 |
| 3/8" | 17.5 | 7.5 | 165.0 | 102.0 |
| 7/16" | 17.5 | 7.5 | 165.0 | 142.0 |
| 1/2" | 19.5 | 8.5 | 185.0 | 178.0 |
| 9/16" | 19.5 | 8.5 | 200.0 | 184.0 |
| 5/8" | 23.5 | 9.5 | 220.0 | 268.0 |
| 11/16" | 23.5 | 9.5 | 220.0 | 268.0 |
| 3/4" | 23.5 | 9.5 | 260.0 | 336.0 |
